| Feed System | User: | Note | Single Note Feeding |
|---|---|---|---|
| Coin | Single Note Feeding | ||
| Retailer: | Note | Bulk-Fedding : 200 Notes / Min. | |
| Coin | Bulk-Fedding : 200 Notes / Min. | ||
| Available Currencies | Local+Optional | (USD,EUR,GBP,CNY and so on) | |
| Counterfeit Detection | Visible Light, Infrared, Magnetic | ||
| Cash Modules | No. of Note Recycler Drum | Desktop ：3 | |
| Duo ：4 | |||
| Cashless ：NA | |||
| No. of Note Cassette | Desktop ：1 | ||
| Duo ：1 | |||
| Cashless ：NA | |||
| No. of Coin Tube | Desktop ：10 | ||
| Duo ：10 | |||
| Cashless ：NA | |||
| Capacity | Note Recycler Drum | 70 Notes / Drum | |
| Note Cassette | 500notes | ||
| Reject Tray | 10notes | ||
| Coin Tube | 70-80pcs / Tube | ||
| Countable Note Size | 500x100x0.06mm ~ 90x185x0.12mm | ||
| Countable Coin Size | Diameter | Ø17-Ø32mm | |
| Thickness | 1.3-3.5mm | ||
| Display | Size | 21.5" | |
| Type | Capacitive Touch | ||
| Client Printer | Printer Type | Thermal | |
| Paper Width | 58mm | ||
| Paper Roll Diameter | <80mm | ||
| Barcode Scanner | 2D, supports 1D barcode | ||
| Interface | LAN, WIFI, 4G (Optional) | ||
| Power Supply | AC 100-240V,50/60Hz | ||
| Consumption | < 200 | ||
| Dimension | Floor Type | 305x450x1700mm | |
| Desktop | 345x520x906mm | ||
| Duo | 350x450x1730mm (base: 685mm) | ||
| Cashless | 141x370x880mm | ||
| Net weight | Desktop | 95kg | |
| Duo | 103kg | ||
| Cashless | 25kg | ||
